GUN: LaB6
Resolution: TEM dot 0.19nm, lattice 0.14nm, STEM DF ~ 1nm
Magnification: ×3,000 ~ × 2,500,000
STEM: JEOL STEM system
Detector: HAADF Detector
EDS: Oxford X-MAX N 100 TLE , Energy resolution 133eV
Chamber Camera: JEOL high Sensitive CMOS CAMERA (FLASH CAMERA)
Bottom mount TVIPS CCD: TemCam-XF416
Camera length: Extension up to 3,500mm
Image area: 63.5 × 63.5 mm² (16M pixel),
High sensitivity
High acquisition speed with large dynamic range.
